National Item Identification Number

01-292-0950
012920950
5305-01-292-0950
5305012920950

National Stock Number

Item Name

SETSCREW

Federal Supply Class

5305

Referenced on: http://www.tpub.com/content/misc_manuals_3/TM-9-2350-311-24P-2/TM-9-2350-311-24P-20402.htm
Referenced on: http://www.tpub.com/content/misc_manuals_3/TM-9-2350-311-24P-2/TM-9-2350-311-24P-20443.htm

Description

An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads.

Commercial and Government Entity Code (Supplier Data)

---

19206

---

---

NSN (National Stock Number) 5305-01-292-0950, 5305012920950 NIIN (National Identification Number) 01-292-0950, 012920950

Part Numbers (Reference Numbers)

11580175

Required Categories

THREAD SERIES DESIGNATOR
NOMINAL THREAD DIAMETER
THREAD QUANTITY PER INCH
THR

Required Description

UNF
0.625 INCHES
18
2A
RIGHT-HAND
0.330 INCHES NOMINAL
0.520 INCHES NOMINA
