National Item Identification Number

01-102-1857
011021857
5305-01-102-1857
5305011021857

National Stock Number

Item Name

SCREW,MACHINE

Federal Supply Class

5305

Referenced on: http://www.tpub.com/content/aviationgenmaint/TM-55-1680-320-23P/css/TM-55-1680-320-23P_466.htm
Referenced on: http://www.tpub.com/content/aviationgenmaint/TM-55-1680-320-23P/css/TM-55-1680-320-23P_474.htm
Referenced on: http://recoveryvehicles.tpub.com//TM-1-1680-320-13-P/0834270355.htm
Referenced on: http://recoveryvehicles.tpub.com//TM-1-1680-320-13-P/0834270380.htm

Description

An externally threaded fastener whose threaded portion is of one nominal diameter, No 0 (0.060 in./1.5 mm) or larger, designed to be held or driven with either a wrench or an inserted driver or both (excluding internal socket or internal multiple spline types), in sizes below No. 10 (0.190 in./5 mm). No. 10 and larger sizes must have a head designed for any type inserted driver (excluding internal socket or internal multiple spline types), but may also be designed for external wrenching. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, CLEVIS; BOLT, EXTERNALLY RELIEVED BODY; SCREW, EXTERNALLY RELIEVED BODY; and SCREW, ASSEMBLED WASHER. See also, SCREW, INSTRUMENT; BOLT, MACHINE; BOLT, INTERNAL WRENCHING; and SCREW, CAP SOCKET HEAD.

Commercial and Government Entity Code (Supplier Data)

---

NSN (National Stock Number) 5305-01-102-1857, 5305011021857 NIIN (National Identification Number) 01-102-1857, 011021857

Part Numbers (Reference Numbers)

AN503-6-12

Required Categories

THREAD SERIES DESIGNATOR
NOMINAL THREAD DIAMETER
THREAD QUANTITY PER INCH
THR

Required Description

UNC
0.138 INCHES
32
3A
RIGHT-HAND
0.656 INCHES MINIMUM AND
0.719 INCHES MA
