National Item Identification Number
01-033-8150
010338150
5305-01-033-8150
5305010338150
National Stock Number
Item Name
SCREW,CAP,HEXAGON HEAD
Federal Supply Class
5305
Description
An externally threaded fastener designed for insertion into holes in assembled parts, for mating with a preformed internal thread and for tightening or releasing by torquing the head. The threaded and unthreaded portions are both of the same nominal diameter of 0.190 inch (5 mm) or larger. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. The thread length being the controlled dimension, the grip length is not specified. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, MACHINE; BOLT, EXTERNALLY RELIEVED BODY; BOLT, INTERNAL WRENCHING; and SCREW, CAP, SOCKET HEAD.
Commercial and Government Entity Code (Supplier Data)
86403
CHRYSLER CORP
SERVICE AND PARTS OPNS
26311 LAWRENCE AVE
CENTER LINE
MI
48015
586-497-0999
NSN (National Stock Number) 5305-01-033-8150, 5305010338150 NIIN (National Identification Number) 01-033-8150, 010338150
Part Numbers (Reference Numbers)
6024487
Required Categories
THREAD SERIES DESIGNATOR
NOMINAL THREAD DIAMETER
THREAD QUANTITY PER INCH
THR
Required Description
UNC
0.375 INCHES
16
RIGHT-HAND
C1 HEXAGON
86403
6024487
