National Item Identification Number

00-737-6095
007376095
5305-00-737-6095
5305007376095

National Stock Number

Item Name

SETSCREW

Federal Supply Class

5305

Description

An externally threaded device whose threaded portion is of one nominal diameter with or without a head and having a cup, cone, or other type of machined point designed to prevent or restrict relative movement of parts and designed to be driven with either a wrench or inserted driver. A locking feature may be incorporated in the design of the head or threads.

Commercial and Government Entity Code (Supplier Data)

---

72447

---

DANA CORP
SPICER UNIVERSAL JOINT DIV
6201 TRUST DR
HOLLAND
OH
43528
419-241-9737

---

19207

---

---

NSN (National Stock Number) 5305-00-737-6095, 5305007376095 NIIN (National Identification Number) 00-737-6095, 007376095

Part Numbers (Reference Numbers)

KC2548
1108D
7376095

Required Categories

THREAD SERIES DESIGNATOR
NOMINAL THREAD DIAMETER
THREAD QUANTITY PER INCH
THR

Required Description

UNF
0.625 INCHES
18
3A
RIGHT-HAND
0.840 INCHES MINIMUM AND
0.880 INCHES MA
