National Item Identification Number
12-322-3196
123223196
5305-12-322-3196
5305123223196
National Stock Number
Item Name
SCREW,MACHINE
Federal Supply Class
5305
Referenced on: http://dieselgenerators.tpub.com//TM-9-6115-668-23P/css/TM-9-6115-668-23P_31.htm
Referenced on: http://dieselgenerators.tpub.com//TM-9-6115-668-23P/css/TM-9-6115-668-23P_430.htmDescription
An externally threaded fastener whose threaded portion is of one nominal diameter, No 0 (0.060 in./1.5 mm) or larger, designed to be held or driven with either a wrench or an inserted driver or both (excluding internal socket or internal multiple spline types), in sizes below No. 10 (0.190 in./5 mm). No. 10 and larger sizes must have a head designed for any type inserted driver (excluding internal socket or internal multiple spline types), but may also be designed for external wrenching. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, CLEVIS; BOLT, EXTERNALLY RELIEVED BODY; SCREW, EXTERNALLY RELIEVED BODY; and SCREW, ASSEMBLED WASHER. See also, SCREW, INSTRUMENT; BOLT, MACHINE; BOLT, INTERNAL WRENCHING; and SCREW, CAP SOCKET HEAD.
Commercial and Government Entity Code (Supplier Data)
D0857
LECHMOTOREN GMBH
ELEKTROMASCHINENBAU
SUEDLICHE ROEMERSTRASSE 12-16
ALTENSTADT
86972
GERMANY
08861-710-0
NSN (National Stock Number) 5305-12-322-3196, 5305123223196 NIIN (National Identification Number) 12-322-3196, 123223196
Part Numbers (Reference Numbers)
425.17.0001
Required Categories
Required Description
