National Item Identification Number
12-195-6413
121956413
5305-12-195-6413
5305121956413
National Stock Number
Item Name
SCREW,CAP,HEXAGON HEAD
Federal Supply Class
5305
Referenced on: http://dieselgenerators.tpub.com//TM-9-6115-668-23P/css/TM-9-6115-668-23P_260.htm
Referenced on: http://dieselgenerators.tpub.com//TM-9-6115-668-23P/css/TM-9-6115-668-23P_429.htmDescription
An externally threaded fastener designed for insertion into holes in assembled parts, for mating with a preformed internal thread and for tightening or releasing by torquing the head. The threaded and unthreaded portions are both of the same nominal diameter of 0.190 inch (5 mm) or larger. Head dimensions and sizes of threaded and unthreaded portions shall conform to internationally recognized fastener standards. The thread length being the controlled dimension, the grip length is not specified. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, MACHINE; BOLT, EXTERNALLY RELIEVED BODY; BOLT, INTERNAL WRENCHING; and SCREW, CAP, SOCKET HEAD.
Commercial and Government Entity Code (Supplier Data)
D8286
DIN DEUTSCHES INSTITUT FUER NORMUNG
EV
BURGGRAFENSTR. 6
BERLIN
10787
GERMANY
030-2601-0
D8286
DIN DEUTSCHES INSTITUT FUER NORMUNG
EV
BURGGRAFENSTR. 6
BERLIN
10787
GERMANY
030-2601-0
D0857
LECHMOTOREN GMBH
ELEKTROMASCHINENBAU
SUEDLICHE ROEMERSTRASSE 12-16
ALTENSTADT
86972
GERMANY
08861-710-0
NSN (National Stock Number) 5305-12-195-6413, 5305121956413 NIIN (National Identification Number) 12-195-6413, 121956413
Part Numbers (Reference Numbers)
DIN933-M12X70-A4-70
M12X70DIN933-A4-70
425.08.2473
